Auto Tracking Antenna System

Long‑range tracking system with 15dBi directional antenna, GPS/Beidou, 360° pan/tilt, IP65, boosts link distance & rate for drones.
GET A QUOTE

Highlights

Product Introduction

This auto tracking antenna system operates at 1300–1500MHz with 15dBi gain and 360° continuous rotation. It supports GPS/Beidou positioning, high-speed PTZ control, and IP65 protection. Designed for quick deployment, it extends transmission distance and improves data rate, ideal for mobile communication and drone data link applications

Feature

• Quick Deployment Solution • Directional Antenna •  High Speed Automatic PTZ •  360° Horizontal Continuous Rotation IncreaseSp •  Transmission Distance •  Improve Transmission Data Rat

Specifications

1.Directional Antenna Frequency Range: 1300～1500MHz Gain: 15dBi SWR: ≤ 2.0 Polarization: Vertical Directional: Vertical 31° Impedance: 50Ohm Connector: SMA Dimension: 380 × 380 × 57mm Material: ABS Weight: 1580g 2. Professional Automatic PTZ Pan Range: 360° Tilt Range: 0°～+90° (-90°～+90° Cus.) Speed: 0.1°～30° / s Tilt Speed: 0.1°～8° / s Protocol: Pelco-D Baud Rate: 2400 / 4800 / 9600 / 19200bps Communication: RS485 Load Bearing: 10000g Power Supply: DC28V (DC24V～36V) Weight: 6500g 3.Tracking Position Mode: GPS / Beidou Accuracy: ≤ 1m Antenna: 33±2dB 4.Physical Operating Temperature: -20°C～+75°C Protection Level: IP65 (Customized)

Accessories

• Directional Antenna × 1 • RF Feeder Cable × 2 • Professional Automatic PTZ × 1 • Quick Release Plate × 1 • Installation Bracket × 1 • Position Antenna × 1 • Tripod × 1 (Optional)

Standard Accessories of /

Optional Accessories of /
